Composite Slate Roofing

Composite Slate Roofing offers the benefits of slate without the many shortcomings. Unlike quarried slate, which usually requires an engineered roof framing system (structural support) because of its weight, Composite Slate Roofing has the aesthetic appeal of slate roofing without the enormous weight. Composite Slate is cast from real slate roofing and the variety of solid and multi colours replicate quarried slate, providing a classic, architectural realistic appearance.

Benefits of Composite Slate Roofing.

Has a natural look of authentic stone slate tiles
Easy to install and little to no breakage
Maintenance free
Lightweight design (Savings in construction cost)
Structurally designed roof line with a 50 year conditional manufacturer warranty
Class A or C Fire Rating, along with the Class 4 Impact Ratings

Download Brochure

Composite Slate Roofing Specifications

Composite Slate roofing can be installed in a staggered application and at two different exposures. This will allow you to choose the look you want.

Profile	Slate - Class A Cavity back		Slate - Class C Cavity back
Exposure	7.5"	6.5"	7.5"	6.5"
Weight/Piece (lb.)	1.8 ± 0.2	1.6 ± 0.2	1.6 ± 0.2	1.6 ± 0.2
Pieces/Square	152	175	152	175
Lb./Square	274	315	244	280
Height	18" ± ⅛"	18" ± ⅛"	18" ± ⅛"	18" ± ⅛"
Width	12 ⅛" ± ⅛"	12 ⅛" ± ⅛"	12 ⅛" ± ⅛"	12 ⅛" ± ⅛"
Pieces/Bundle	10	10	10	10
Bundles/Square	15.2	15.2	15.2	15.2
Squares/Pallet	6.3	5.4	7.8	6.8
Fire Rating	Class A	Class A	Class C	Class C
Impact Rating	Class 4	Class 4	Class 4	Class 4

Composite Slate Roofing Accessories

Starter: 10.5" Length x 12⅛" ± ⅛" Width

Starters will provide the proper cant at the eave line for the first row of slate.

Hip & Ridge: 16" Length x 6" x 5-5/8" Width

The hip/ridge trim allows for a professional finish for a beautiful roof. At least a three inch overlap is required for installation.

Solid Tile Accessory: 18" ± ⅛" Length x 12⅛" ± ⅛" Width

Solid tile accessories provide the authentic appearance of slate at the gables, and assists in the installation of open valleys which can be labor intensive when using other composites with a honeycomb core.

Composite Slate Roofing Testing

Composite Slate has passed the stringent testing required for premier roofing products. The chart below shows the important ratings of Class 4 impact and Class A and C fire. These are the highest ratings in the industry.

Testing Performed	Standard Met	Slate - Class A	Slate - Class C
Weatherometer	ASTM G 26	Pass	Pass
Fire Resistance	UBC 15-2; ASTM E 108; or UL 790	Class A	Class C
Impact Resistance	UL 2218	Class 4	Class 4
Wind Resistance	ASTM D 3161;	Pass
Wind-driven Rain	Dade County 100-95	(90 mph)
Uplift Bend	ICC-ES AC07, Section 4.4	Pass
Temperature-Cycling	ICC-ES AC07, Section 4.9	Pass
Penetration	ICC-ES AC07, Section 4.5	Pass
